Product Details:
Payment & Shipping Terms:
|
| Name: | AISI201 Stainless Steel Coils | Specification: | Cold Rolled Or Hot Rolled |
|---|---|---|---|
| Grade: | SUS201 SUS304 SUS304L Etc | Edge: | Mill Edge Or Slit Edge |
| Thickness: | 0.3mm-3.00mm | Diamenter: | Width 1000mm-1550mm*Length |
| High Light: | stainless steel strip coil,SS coil |
||
AP Finish Mill Edge Stainless Steel SS Coil JIS4305 SUS201 SUS304 SUS304L Standard
Quick Detail:
Standard:JIS, AISI, ASTM, GB, DIN,SUS
Thickness:0.3-3.0mm
Diameter:1000-1550mm
Application:Kitchenware, decoration, construction and building ornament, product parts manufacturing and stainless steel products tooling and so on
Surface Treatment:2B, BA, Hair Line, No.1,No.4, Mirror Finish
Certification:SGS
Technique:Cold rolled
Cr Content:12.5-13.5%
Sample:FREE SAMPLES can be sent on request. We promise to provide our valued clients with high quality products, low price, and excellent client services.
|
Standard |
Chemical Composition |
|||||||
|
ASTM A240 |
DIN |
EN 10088-2 |
JIS4305 |
C% Max |
Si% Max |
Mn% Max |
Cr% |
Ni% |
|
201 |
|
|
SUS201 |
0.15 |
1.00 |
7.50 |
16.00-18.00 |
3.50-5.50 |
|
202 |
|
|
SUS202 |
0.15 |
1.00 |
10.00 |
17.00-19.00 |
4.00-6.00 |
|
304 |
1.4301 |
X5CrNi18-10 |
SUS304 |
0.08 |
1.00 |
2.00 |
18.00-20.00 |
8.00-10.50 |
|
304L |
1.4306 |
X2CrNi19-11 |
SUS304L |
0.03 |
1.00 |
2.00 |
18.00-20.00 |
8.00-12.00 |
|
309S |
1.4833 |
X12CrNi23-13 |
SUS309S |
0.08 |
1.00 |
2.00 |
22.00-24.00 |
12.00-15.00 |
|
310S |
1.4845 |
X8CrNi25-21 |
SUS310S |
0.08 |
1.00 |
2.00 |
24.00-26.00 |
19.00-22.00 |
|
316 |
1.4401 |
X5CrNiMo17-12-2 |
SUS316 |
0.08 |
1.00 |
2.00 |
16.00-18.00 |
10.00-14.00 |
|
316L |
1.4435 |
X2CrNiMo17-12-2 |
SUS316L |
0.03 |
1.00 |
2.00 |
16.50-18.50 |
10.00-14.00 |
|
317 |
1.4449 |
|
SUS317 |
0.08 |
1.00 |
2.00 |
18.00-20.00 |
11.00-15.00 |
|
317L |
1.4438 |
X2CrNiMo18-15-4 |
SUS317L |
0.03 |
1.00 |
2.00 |
18.00-20.00 |
11.00-15.00 |
|
321 |
1.4541 |
X6CrNiTi18-10 |
SUS321 |
0.08 |
1.00 |
2.00 |
17.00-19.00 |
9.00-12.00 |
|
347 |
1.4550 |
X6CrNiNb18-10 |
SUS347 |
0.08 |
1.00 |
2.00 |
17.00-19.00 |
9.00-12.00 |
|
410 |
1.4006 |
X12Cr13 |
SUS410 |
0.15 |
1.00 |
1.00 |
11.50-13.50 |
(≤ 0.75) |
|
420 |
1.4021 |
X20Cr13 |
SUS420J1 |
0.16-0.25 |
1.00 |
1.00 |
12.00-14.00 |
|
|
430 |
1.4016 |
X6Cr17 |
SUS430 |
0.12 |
1.00 |
1.00 |
16.00-18.00 |
|
|
Technique: Cold rolled Or Hot Rolled |
||||||||
|
Surface finish: 2B, BA, AP ( Annealed & Pickled ) |
||||||||
|
Size: Thickness 0.3mm-3mm, Width 1000mm-1550mm, Length coil |
||||||||
Applications
We,this material stainless steel plates be widely used in kinds of industries:
Specifications
Designation: A240/A 240M-04a
Standard specifications For Chromium and Chromium-Nickel Stainless Steel Plate,Sheet, and Strip for Pressure Vessels and for General Applications
|
This specification covers |
Chromium and chromium Nickel Stainless Steel Plate,Sheet, and Strip for Pressure Vessels and for General Applications |
|
Permitted Variations In Thickness for Cold-Rolled, Narrow, Coil-Processed Product as Coils and Cut Lengths
|
Thickness Tolerance,for the thickness and widths given.Over and Under,in. Width(w), in. w≤6, inc 6＜w≤12, inc 12＜w＜24, inc Specified Thickness,in. Thickness Tolerances 0.002 to 0.005,excl 10% 10% 10% 0.005to 0.010, incl 10% 10% 10% 0.005to 0.010, incl 0.0006 0.0008 0.001 Over 0.010 to 0.011, incl 0.0015 0.0015 0.0015 Over 0.010 to 0.012, incl 0.001 0.001 0.001 Over 0.011 to 0.013, incl 0.0015 0.0015 0.002 Over 0.013 to 0.017, incl 0.0015 0.002 0.002 Over 0.012 to 0.015, incl 0.001 0.0015 0.0015 Over 0.017 to 0.020, incl 0.0015 0.002 0.0025 Over 0.015 to 0.020, incl 0.001 0.0015 0.0015 Over 0.020 to 0.029, incl 0.002 0.0025 0.0025 Over 0.029 to 0.035, incl 0.002 0.002 0.002 Over 0.035 to 0.050, incl 0.0025 0.0035 0.0035 Over 0.050 to 0.069, incl 0.003 0.003 0.003 Over 0.069 to 0.100, incl 0.003 0.003 0.004 Over 0.100 to 0.125, incl 0.004 0.004 0.005 Over 0.125 to 0.161, incl 0.005 0.005 0.005 ........ ...... ...... ...... |
|
Section 11 |
No.1 Finish → Hot-rolled,annealed and descaled. No.2D Finish → Cold-rolled,dull finish No.2B Finish → Cold-rolled,bright finish Bright Annealed Finish → A bright cold-rolled finish retained by final annealing in a controlled atmosphere furnace No.3 Finish → Intermediate polished finish,one or both sides No.4 Finish → General purpose polished finish,one or both sides No.6 Finish → Dull satin finish,Tampico brushed,one or both sides No.7 Finish → High luster finish No.8 Finish → Cold-worked to obtain specified properties. |
|
Section 12 |
No.1 Finish → Cold-rolled to specified thickness,annealed and descaled No.2D Finish → Same as No.1 finish,followed by a final light cold-roll pass,generally on highly polished rolls Bright Annealed Finish → A bright cold-rolled finish retained by final annealing in a controlled atmosphere furnace TR Finish → Cold-work to obtain specified properties Polished Finish → Stainless steel strip is also available in polished finishes such as No.3 and No.4,which are explained in Note4. |
|
Section 13 |
Hot-rolled or Cold-rolled,and Annealed or Heat treated → Scale not removed,an intermediate finish,Use of plates in this condition is generally confined to heat-resisting applications. Scale impairs corrosion resistance. Hot-rolled or Cold-rolled,and Annealed or Heat treated,and Blast cleaned or Pickled → Condition and finish commonly preferred for corrosion-resisting and most heat-resisting applications, essentially a No.1 Finish. Hot-rolled or Cold-rolled,and Annealed or Heat treated,and surface cleaned and polishe → Polish finish is generally No.4 Finish. Hot-rolled or Cold-rolled,and Annealed or Heat treated,and Descaled; and Cold-rolled, and Annealed Or Heat treated,and Descaled,and Optionally temper passed → Smooth finish with greater freedom from surface imperfections than in 13.1.4 |
|
Section 14 |
No.1 Edge → A rolled edge,either round or square as specified No.3 Edge → An edge produced by slitting. No.5 Edge→ An approximately square edge produced by rolling or filing after slitting |
