Welded Line Pipe API 5L

: Large Image : Welded Line Pipe API 5L

Product Details:

Place of Origin:	China
Brand Name:	TPCO, CHANG JIANG PIPE, CANGZHOU SSAW,LSAW Etc.
Certification:	ISO,SGS,CQC,etc.
Model Number:	Q235,Q345,L245,L290L360,16Mn,X42,X46,X70,X80,0Cr13,1Cr17,1Cr18Ni9 etc

Payment & Shipping Terms:

Minimum Order Quantity:	500Kgs/ one size
Price:	Negotiation
Packaging Details:	Plastic bag in bundle,Wooden box,etc.
Delivery Time:	20-25 days
Payment Terms:	T/T, L/C at sight
Supply Ability:	600Tons/Month

Contact Now

Detailed Product Description

End:	Plain End	Certification::	API & ISO & PED
Cold Drawn From Size:	3/4"-5" OD Pipe	Hot Rolled From Size:	1"-16" OD Pipe
Hot Expand Pipe From Size:	20"-24"	ERW Steel Pipe Size:	1/4"-24"
Sprial Welded Pipe From:	6"-108"
High Light:	erw line pipe , api 5l grade b pipe

ASTM / DIN / JIS , Line Pipe API 5L Welded Pipes Used in Oil And Gas Industries

Quick Detail:

Standard	ASTM / DIN / JIS
Type	Welded
Technique	Cold Drawn
Material	Gr.B,X42,X52,X60,X65,X70
Size	8"--72"
Thickness	Sch10--Schxxs
Usage	Pipeline Transport, Special Purpose, Machinery Industry, Chemical Industry, Thermal Equipment
Application	Structure Pipe, Fluid Pipe, Oil Pipe, Boiler Pipe, Chemical Fertilizer Pipe, Gas Pipe, Hydraulic Pipe, Drill Pipe
Market	USA,Ukraine,Russia,Middle east etc.

Description:

Size:
1, Cold drawn from size 3/4"-5" OD pipe.
2, Hot rolled from size 1"-16" OD pipe
3, hot expand pipe from size 20"-24"
4, ERW steel pipe from 1/4"-24"
5, Sprial welded pipe from: 6"-108"
Wall thickness: SCH5s, SCh10, SCH20, SCH30, SCH40, STD, SCH60, SCH80, SCH120, XS, XXS, etc / 6mm - 25mm
Standard:
GB: GB/T 8162— 2008, GB/T5310, SY/T5037 SY/T5040 GB/T9711, SY/T3091-2001
ASTM: API 5L/ API5CT/ ASTM A106 /ASTM A53/ASTM A333 ASTM A335
DIN: DIN 17175, DIN1629/4, DIN17440, DIN1626
JIS: G3454, G3461, G 3456, G3462, G3458, A5525
Material:
GB: 10#, 20#, 45#, 16Mn
ASTM: Carbon steel: A106Gr. A/B, A53Gr. A/B, API5L Gr B X42/52/60
Stainless steel: A312/A213 TP304/304L/316/316L/317/321/321H, etc
Alloy steel: A 335 P1/P5/P9/P11P12/P22/P91
DIN: ST37.0, ST35.8, ST42, ST45-8/ST52, 15Mo3, 13CrMo44, 10CrMo910, etc
JIS: G3454-STPG370/410, G3444-STK400, G3452-SGP, etc
Certification: API & ISO & PED
Inspection: With Chemical Composition and Mechanical Properties Testing; Hydrostatic Test,
Dimensional and Visual Inspection, Also With Nondestructive Inspection
Ends: Beveled (Can be Protected By Plastic Caps or Steel Rings According to Your Requirements)Also We Can Weld Flanges on the Pipe Ends Plain Ends
Surface:
1.bare
2.varnished coating
3.black lacquer coating
4.bitumen Coating
5.anti-corrosion coating
5.3PE,
6.cement Mortar
7. epoxy coating
8.customer's requiremen
Package: Package With Steel Strip When O. D≤ 273MM, Otherwise In Bulk.

Applications:

We,this type pipe be widely used in kinds of ares during transportation,like

Natural gas
Petroleum
Chemical industry
Power
Heat power
Water source etc.

API SPEC 5L Specifications

Nominal Size	Outside Diameter	Wall Thickness	Plain-end Weight
inch	mm	inch	mm	lb/ft	kg/m
0.405	0.405	10.29	0.095	2.4	0.31	0.47
0.54	0.54	13.72	0.088	2.2	0.43	0.62
0.54	13.72	0.119	3.0	0.54	0.79
0.675	0.675	17.15	0.091	2.3	0.57	0.84
0.675	17.15	0.126	3.2	0.74	1.10
0.84	0.84	21.34	0.109	2.8	0.85	1.28
0.84	21.34	0.147	3.7	1.09	1.61
1.05	1.05	26.67	0.113	2.9	1.13	1.70
1.05	26.67	0.154	3.9	1.48	2.19
1.315	1.315	33.4	0.133	3.4	1.68	2.52
1.315	33.4	0.179	4.6	2.17	3.21
1.660	1.660	42.2	0.145	3.7	2.72	3.43
1.660	42.2	0.191	4.9	3.00	4.51
1.900	1.660	42.2	0.382	9.7	5.22	7.77
1.900	48.3	0.145	3.7	2.72	4.07
1.900	48.3	0.200	5.1	3.63	5.43
1.900	48.3	0.400	10.2	6.41	9.58
2 3/8	2.375	60.3	0.109	2.8	2.64	3.97
2.375	60.3	0.125	3.2	3.00	4.51
2.375	60.3	0.141	3.6	6.36	5.03

Our advantage

X-ray industrial TV
Offline ultrasonic flaw detector
Hydro-static testing machine
Metallographic testing machine
Good after sales services
Good package
