High Precision Seamless Food Grade Stainless Steel Tubing 304 304L 316L

Good quality Stainless Steel Pipe Fitting for sales
Good quality Stainless Steel Pipe Fitting for sales
I'm Online Chat Now

High Precision Seamless Food Grade Stainless Steel Tubing 304 304L 316L

China High Precision Seamless Food Grade Stainless Steel Tubing 304 304L 316L supplier

Large Image :  High Precision Seamless Food Grade Stainless Steel Tubing 304 304L 316L

Product Details:

Place of Origin: China
Brand Name: Hainer Steel
Certification: ISO9001,SGS,CQC,BV, TUV etc.
Model Number: 201,202,304,304L,316L,2205,904L etc.

Payment & Shipping Terms:

Minimum Order Quantity: 500Kgs/ one size
Price: Negotiation
Packaging Details: Plastic bag in bundle,Wooden box,etc.
Delivery Time: 15-20days or Stock
Payment Terms: T/T, L/C at sight
Supply Ability: 2000Tons/Month
Detailed Product Description
Welding Line Type: ERW Material Number: 201,202,304,304L,316L,2205,904L Etc.
Tolerance: High-Precision +/-0.02mm
High Light:

Sanitary Stainless Steel Tubing

,

Food Grade Stainless Steel Pipe



High Precision Seamless Food Grade Stainless Steel Tubing 304 304L 316L





Quick Detail:



  • Standard: JIS, AISI, ASTM, GB, DIN, EN
  • Steel Grade:316L,304,321,316L,304L,309S,310S,201,202 ,410,430 etc.
  • Outside Diameter: 6mm to 450mm
  • Thickness: 1mm to 20mm
  • Type: Seamless Or Welded
  • Surface: Bright Annealing, Mirror Polish, Hairline Polish




Description:



  1. Product Item No.: 0015foodtube-Cosco Steel
  2. Standard: ASTM A554, A312, A249, A269 and A270
  3. Material Grade:201 202 304 316L 304L 321 410 430,etc.
  4. Thickness:wide thickness: 1-20mm; Outer diameter: 6-450mm
  5. Length:6m or as required
  6. Tolerance:
    a) Outer Diameter:  +/- 1%
    b) Thickness: +/- 0.02mm
    c) Length: +/- 5mm
  7. Surface:180G, 320G, 400G Satin / Hairline(Matt Finish, Brush, Dull Finish),400G, 500G, 600G or 800G Mirror finish
  8. Test: Squash test, Extended test, Water pressure test, Crystal rot test, Heat treatment, NDT





Chemical Standard and Mechanical Propertie










Chemical Composition

of Material ( % )

Material Item

201

202

304

316

430

C

≤0.15

≤0.15

≤0.08

≤0.08

≤0.12

Si

≤1.00

≤1.00

≤1.00

≤1.00

≤1.00

Mn

5.5-7.5

7.5-10

≤2.00

≤2.00

≤1.00

P

≤0.06

≤0.06

≤0.045

≤0.045

≤0.040

S

≤0.030

≤0.030

≤0.030

≤0.030

≤0.030

Cr

16-18

17-19

18-20

16-18

16-18

Ni

3.5-5.5

4-6

8-10.5

10-14



Mo







2.0-3.0





Mechanical Property

Material Item

201

202

304

316

Tensile Strength ( Mp a )

≥535

≥520

≥520

≥520

Yield Strength ( Mp a )

≥245

≥205

≥205

≥205

Extension

≥30%

≥30%

≥35%

≥35%

Hardness (HV)

<253

<253

<200

<200





Applications:



We,this type seamless and welded food steel tube be widely in food production all over the world

In passed many years,the factories be warmly welcome to use food bright surface both inside and outside stainless steel tubeing,in order to reach high quality from European,Japanese and others countries,we owned a set of advanced equirpment for material chemical component test,physical performance test and hydraulic test etc.





Our advantage



  1. Bright Annealing
  2. Strict tolerance control
  3. Good quality control system
  4. Good after sales services
  5. Good package

High Precision Seamless Food Grade Stainless Steel Tubing 304 304L 316LHigh Precision Seamless Food Grade Stainless Steel Tubing 304 304L 316L
