ASTM A312 TP304 / 304L 316L Welded Stainless Steel Pipe 16 inch with Hot Finished

Good quality Stainless Steel Pipe Fitting for sales
Good quality Stainless Steel Pipe Fitting for sales
I'm Online Chat Now

ASTM A312 TP304 / 304L 316L Welded Stainless Steel Pipe 16 inch with Hot Finished

China ASTM A312 TP304 / 304L 316L Welded Stainless Steel Pipe 16 inch with Hot Finished supplier
ASTM A312 TP304 / 304L 316L Welded Stainless Steel Pipe 16 inch with Hot Finished supplier ASTM A312 TP304 / 304L 316L Welded Stainless Steel Pipe 16 inch with Hot Finished supplier

Large Image :  ASTM A312 TP304 / 304L 316L Welded Stainless Steel Pipe 16 inch with Hot Finished

Product Details:

Place of Origin: China
Brand Name: Cosco Steel
Certification: ISO,SGS,CQC,etc.
Model Number: Tp304 / 304L, Tp316L, Tp310S, SUS630, SUS631

Payment & Shipping Terms:

Minimum Order Quantity: 500Kgs/ one size
Price: Negotiation
Packaging Details: Plastic bag in bundle,Wooden box,etc.
Delivery Time: 25-30 days
Payment Terms: T/T, L/C at sight
Supply Ability: 600Tons/Month
Contact Now
Detailed Product Description
Diameter: 8 Inch, 10 Inch, 12 Inch, 16 Inch, 18 Inch, 20 Inch, 22 Inch Etc Wall Thickness: 3mm, 4mm, 5mm,6mm,8mm,10mm,12mm Etc
Heat Treatment Method: Hot Finished | Cold Finished And Annealed Surface: Pickled



ASTM A312 TP304 / 304L 316L Welded Stainless Steel Pipe 16 inch with Hot Finished





Quick Detail:



Surface Finish

1. 2B Finish  2. Pickled Finished  3. Annealed&Pickled

Material

304/L, 316L/Ti, 310S etc.

Outside Diameter

6mm - 200mm

Wall Thickness

0.5-20mm.

Length

As required

Market

USA,Canada,Japanese,European etc.





Description:

  1. Product Item No.: 0050welded-Cosco Steel
  2. Type: Round
  3. Mainly Material

  1. 4301/ SUS304/ AISI304/ S30400,

  1. 4306/ SUS304L/ AISI304L/ S30403,

  1. 4404/ SUS316L/ AISI316L/ S31603, etc.





Standard:



  GB/T12771-2008, ASTM A312, ASTM A789, JIS G3448,

  DIN EN10216-5, DIN EN10217-7, etc.

  1. Size: 8 In. to 48 In.
  2. Wall Thickness: 3mm to 20mm
  3. Marking: Registered logo,Heat Number,Steel Grade,Standard,Size
  4. H.S Code: 7306.4000



Applications:



This type welded tubes/pipes be used in

  1. Industrial fluid conveying pipes
  2. Mechanical structural tubes
  3. Heat ex-changer and condenser tubes
  4. Walled water tubes
  5. Larger caliber industrial welded pipes etc.



Specifications



Designation: A312/A312M-04a

Standard specifications For Seamless,Welded,And Heavily Cold Worked Austenitic

Stainless Steel Pipe



Manufacture Process

ERW Welded ( ELD ) Pipe







Quality Inspection







  1. Metallographic Analysis
  2. Physical And Chemical Analysis
  3. Specification Eccentricity Test
  4. Mechanical Test
  5. PMI Test
  6. Eddy Current Test
  7. Large-Size Ultrasonic Flaw Test
  8. Ultrasonic Flat Test
  9. Thickness Test   etc.







Mechanical Requirements

 Grade    UNS              Tensile Strength   Yield Strength

             Designation     Min Ks i [M pa]     Min Ks i [M pa]

 TP304    S30400             75 [515]         30 [205]

 TP304L   S30403             70 [485]         25 [170]

 TP309S   S30908             75 [515]         30 [205]

 TP310S   S31008             75 [515]         30 [205]

 TP316L   S31603             70 [485]         25 [170]

  ....          ....                .....               .....

  1. Specification No.
  2. Pipe
  3. Grade
  4. NPS
  5. Wall
  6. SMLES OR WELDED ...
  • ASTM A312
  • P
  • TP304
  • 12IN
  • 0.375 IN
  • WELDED .....
